Erase DTC Memory (function 05): Procedure

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2005 Audi allroad, 2004 Audi allroad, 2004 Audi A6, 2003 Audi allroad, and 2003 Audi S6. However, it is still accessible from the selected car via links, so may be relevant.

After successful DTC memory check:

Display on VAS 5051:

Fig 1: Display On VAS 5051 - Erase DTC Memory (Parking Assistance) (1 Of 2)

Courtesy of AUDI OF AMERICA, INC.

In selection -1-, click on the diagnostic function "05- Check DTC Memory".

Display on VAS 5051:

- no indication (before erasing)
- DTC memory erased
Fig 2: Display On VAS 5051 - Erase DTC Memory (Parking Assistance) (2 Of 2)
Courtesy of AUDI OF AMERICA, INC.

NOTE: If indication -1- appears in display field: "DTC memory has not yet been checked", the work sequence was not adhered to correctly. DTC memory can only be erased if DTC memory was checked before.
Note: Perform the function? Note: Data is being erased !

Press on "OK"-button in display -2-.
End function "05 - Erase DTC Memory" by pressing on <-- button.
