End Output (function 06)

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2005 Audi allroad, 2004 Audi allroad, 2004 Audi A6, 2003 Audi allroad, and 2003 Audi S6. However, it is still accessible from the selected car via links, so may be relevant.

Display on VAS 5051:

Fig 1: Display On VAS 5051 - End Output (Parking Assistance) (1 Of 2)

Courtesy of AUDI OF AMERICA, INC.

Select diagnostic function "06 - End Output" in selection -1-.

Display on VAS 5051:

Fig 2: Display On VAS 5051 - End Output (Parking Assistance) (2 Of 2)

Courtesy of AUDI OF AMERICA, INC.

Switch off ignition and disconnect diagnostic connector after this indication is displayed.
