Headlight beam adjusting motors -V48-/-V49-, removing and installing: Removing: Notes

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2005 Audi allroad, 2004 Audi allroad, 2004 Audi A6, 2003 Audi allroad, and 2003 Audi S6. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: Always adjust headlights after adjusting motors are removed and installed or are replaced. See HEADLIGHTS, ADJUSTING .

Remove both bolts -1- at air intake channel and then pull up at rear part of intake channel -2- (only for right headlight).

Fig 1: Removing Bolts & Pulling Up Rear Part Of Intake Channel

Courtesy of AUDI OF AMERICA, INC.

Remove housing cover from headlight housing.
