Dashboard Wire Harness (View of passenger's side)
WARNING: This page is about a different car, the 2007 Acura CSX and 2006 Acura CSX. However, it is still accessible from the selected car via links, so may be relevant.
CONNECTOR AND TERMINAL CHART
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes | ||
|---|---|---|---|---|---|---|---|
| Cable reel connector A | 16 | 4 | In steering column cover | Driver's airbag inflator | |||
| Cable reel connector B | 2 | 20 | In steering column cover | Steering wheel switches | |||
| Climate control unit | 12 | 32 | Under middle of dash | ||||
| Combination light switch | 1 | 12 | In steering column cover | ||||
| Glove box light | 4 | 2 | Under right side of dash | ||||
| Ignition switch | 13 | 7 | In steering column cover | ||||
| Ignition key switch/key interlock solenoid | 14 | 6 | In steering column cover | ||||
| Immobilizer-keyless control unit | 15 | 7 | In steering column cover | ||||
| Passenger's airbag inflator | 9 | 4 | Under right side of dash | ||||
| Right tweeter | 5 | 2 | Right side of dash | ||||
| Steering angle sensor | 17 | 5 | In steering column cover | (1) | |||
| Wiper/washer switch | 3 | 8 | In steering column cover | ||||
| C504 | 10 | 24 | Under middle of dash | A/C wire harness (see A/C WIRE HARNESS ) | |||
| C761 | 7 | 23 | Under right side of dash | Front passenger's door wire harness (see FRONT PASSENGER'S DOOR SUBHARNESS ) | |||
| C762 | 6 | 18 | Under right side of dash | Front passenger's door wire harness (see FRONT PASSENGER'S DOOR SUBHARNESS ) | |||
| G502 | 8 | Under right side of dash | Body ground, via dashboard wire harness | ||||
| G505 | 11 | Behind left side of glove box | Body ground, via dashboard wire harness | ||||
|
|||||||
