Transmission Cover, Control System [2016, B5254T12, TF-80SC AWD]: Removal
NOTE:
Removal steps in this procedure may contain installation details.
Remove the air filter housing, refer to: AIR CLEANER HOUSING
Drain oil transmission, refer to: TRANSAXLE OIL
WARNING:
Be prepared to collect escaping fluid.
CAUTION:
Make sure that all openings are sealed.
Torque: M6, 10Nm
Torque: Cover, control system, 13Nm
WARNING:
Make sure that the component is clean, free of foreign material and lubricant.
Use: Cleaning agent, 1161721
