Battery Relay [2016-2018]: Removal

NOTE:

Removal steps in this procedure may contain installation details.

Perform battery disconnecting and connecting, refer to: BATTERY DISCONNECTING AND CONNECTING

Remove the plenum cover, refer to: PLENUM COVER

Courtesy of VOLVO CARS CORPORATION

Courtesy of VOLVO CARS CORPORATION

Courtesy of VOLVO CARS CORPORATION

Torque: M6, 10Nm

Courtesy of VOLVO CARS CORPORATION

Torque: M8, 24Nm

Courtesy of VOLVO CARS CORPORATION
