High-Pressure Washer Headlamp, Replacing: Removal

Fig 1: Detach The Cover From The Nozzle

Courtesy of VOLVO CARS CORPORATION

Pull the cover straight out.

Detach the cover from the nozzle as illustrated.

Disconnect the washer hose.

Fig 2: Identifying Headlamp Washer Components

Courtesy of VOLVO CARS CORPORATION

Remove:

• the screws
• the clip
• the high-pressure washer.
