Installing The Brake Pipes

Fig 1: Identifying Protective Cover

Courtesy of VOLVO CARS CORPORATION

Install:

• the brake pipe (1). Tighten. See TIGHTENING TORQUE
• the brake pipe (2). Tighten. See TIGHTENING TORQUE
• the brake pipe in the clips.
