Air Bag, Front Seat (2010): Removal

NOTE:

Removal steps in this procedure may contain installation details.

Perform battery disconnecting and connecting, see BATTERY DISCONNECTING AND CONNECTING

Fig 1: Identifying Generator Removal Procedure (1 Of 4)

Courtesy of VOLVO CARS CORPORATION

Follow instruction for handling of non-deployed pyrotechnical part, see HANDLING NON-DEPLOYED PYROTECHNICAL PART (2010)

Follow instructions about safety information pyrotechnical system, see SAFETY INFORMATION PYROTECHNICAL SYSTEMS

Follow the instructions about positioning safety components. See POSITIONING SAFETY LABELS

Remove the upholstery, see FRONT SEAT BACKREST

Fig 2: Identifying Front Seat Connectors

Courtesy of VOLVO CARS CORPORATION

Fig 3: Locating Ground Bolt

Courtesy of VOLVO CARS CORPORATION

Torque: M6

10 Nm

Fig 4: Locating Air Bag To Seat (SIPS) Bolt

Courtesy of VOLVO CARS CORPORATION

Torque: Air bag to seat (SIPS)

7 Nm

Perform connector ignition cable, see IGNITER WIRE CONNECTOR

Fig 5: Front Seat Air Bag Connector

Courtesy of VOLVO CARS CORPORATION
