Collecting Oil

Fig 1: Identifying Rear Axle Oil, 1161620
GLL170393Courtesy of VOLVO CARS OF NORTH AMERICA.
CAUTION:

The fluid must be allowed to escape until a continuous flow changes into single drops.

Use:  Rear axle oil, 1161620
