Aligning the fog lamps: Adjustment

WARNING: This page is about a different car, the 2004 Volvo S40, 2003 Volvo S40, 2002 Volvo S40, 2001 Volvo S40, and 2000 Volvo S40. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Adjusting Lamp Setting By Turning Adjustment Screw

Courtesy of VOLVO CARS OF NORTH AMERICA.

Remove the air baffle.

Adjust the lamp setting by turning the adjustment screw.

NOTE: Beam adjustment must be carried out in accordance with the relevant national statutory requirements.
