Installing The Brake Fluid Reservoir

NOTE:

Check the seals. Replace if necessary.

NOTE:

Only use brake fluid to lubricate the seal rings in the brake system.

Fig 1: Installing Brake Fluid Reservoir

Courtesy of VOLVO CARS CORPORATION

Install:

the brake fluid reservoir -
the 1 screw on the side of the brake fluid reservoir. Tighten. See: TIGHTENING TORQUE .
