Removing Snow Chains: Removal

Fig 1: Open Safety Catches

Courtesy of VOLVO CARS OF NORTH AMERICA.

Fig 2: Pulling Lever Past Its Catch Position

Courtesy of VOLVO CARS OF NORTH AMERICA.

Fig 3: Pressing Yellow Button & Pulling Mounting Arm From Adapter

Courtesy of VOLVO CARS OF NORTH AMERICA.

Fig 4: Grasping Snow Chain At Top With Both Hands & Shake Chain Vigorously While Pulling It From Wheel

Courtesy of VOLVO CARS OF NORTH AMERICA.

Grasp the snow chain at the top with both hands. Shake the chain vigorously while pulling it from the wheel.
