Installing upholstery on center backrest cushion (second row)

Fig 1: Identifying Installation Of Weatherstrip Into Channel In Rear Section

Courtesy of VOLVO CARS OF NORTH AMERICA.

Install:

• the upholstery for the cushion
• the rear section on the backrest frame
• the 3 screws. Tighten
• the upholstery / cushion on the backrest frame.

Fold in the weatherstrip into the channel in the rear section.

Start with the upper molding, then the lower molding and finally the moldings on the sides.

Install:

• the guide sleeves for the head restraint
• the bracket for the seat belt
• the 2 screws. Tighten
• the head restraint.
