Installing the connector and cable harness

Fig 1: Identifying Gearbox Cable And Gearbox Lever

Courtesy of VOLVO CARS OF NORTH AMERICA.

Hook the connectors into place on the mounting. Connect the connectors.

Install:

• the tie straps around the cable harness. Secure the cable harness in the cover for the control system
• the mounting for the cable harness on the bracket for the air cleaner (ACL)
• the gear selector cable and bracket. Tighten. See: Summary of tightening torques for specific components . Connect the cable to the lever.

Fig 2: Identifying Air Cleaner Housing Assembly And Intake Pipe

Courtesy of VOLVO CARS OF NORTH AMERICA.

Install the air cleaner (ACL) housing.
