Connecting the manometer, applies to model years from and including 2005

Fig 1: Identifying Manometer Connectors, Hoses & Gauge
GLL172721Courtesy of VOLVO CARS OF NORTH AMERICA.

Connect 9995055 version D, between the pump and the steering gear's pressure hose.

Use 9997179 and 9997180 .

NOTE: Connect the hose from the pressure gauge valve to the steering gear's pressure hose. The valve should be parallel with the hose.

Remove:
