Removing The Handset

Fig 1: Connector Rubber Grommet

GLL106213

Courtesy of VOLVO CARS OF NORTH AMERICA.

Remove:

two screws (1)
the ashtray. See Rear ashtray .

Disconnect the connector.

Remove the rubber grommet.
