Removing the fan unit
Courtesy of VOLVO CARS OF NORTH AMERICA.
Separate the gray connector. Disconnect the gray connector from the air baffle for the radiator.
Remove the canister purge (CP) valve and the cable clip.
Remove:
- the 3 screws retaining the air baffle
- the engine cooling fan (FC).
