Remove the Support Arm

Fig 1: Identifying Hub Cap, Center Nut, Whole Hub, Brake Disc, Splashguard And Support From Hub With Screws

Courtesy of VOLVO CARS OF NORTH AMERICA.

Support the lower control arm.

Remove the mounting for the lower control arm. Remove the upper control arm on the trailing arm.

Remove the screw from the front rubber bushing. Remove the trailing arm.
