Removing relay

Fig 1: Locating The Central Electrical Unit

Courtesy of VOLVO CARS OF NORTH AMERICA.

The central electrical unit is located in the passenger compartment on the driver's side under the soundproofing panel.

Remove:

• The battery ground cable.
• Soundproofing panel screws.
• Soundproofing panel.
