Fitting the passenger airbag module
WARNING:
Follow the instructions when handling the passenger module. See Handling non-deployed airbag modules / pyrotechnic seat belt tensioners .
Carefully fit the passenger module into place in the dashboard.
Fit:
- the two bolts to 9 Nm .
- the breather pipe with four bolts.
- the green connector of the passenger module.
WARNING:
Never use an ohmmeter or any other conducting instrument for measuring a disconnected, undeployed passenger airbag module. It could cause the passenger module to deploy.
