Control module security strap, replacement: Installation
CAUTION:
Before reinstalling the security strap, ensure that the car has been repaired and that no faults remain.
- Ensure that the slot on the underside of the control module is in the correct position, and secure it by hooking on the strap.
- Fold up security strap over the control module box cover.
- Secure the locking strip by tightening the security screw (P/N 980471-7) so that its head breaks off.
