Fault-tracing information

WARNING: This page is about a different car, the 2002 Volvo C70, 2001 Volvo C70, 2000 Volvo C70, 1999 Volvo C70, and 1998 Volvo C70. However, it is still accessible from the selected car via links, so may be relevant.

Condition

Fig 1: Identifying Differential

Courtesy of VOLVO CARS OF NORTH AMERICA.

The problem occurs when a gear is engaged. It is especially apparent when the transmission is hot.

Possible Source

Defective synchronizer.

Fault symptom[s]

Scraping noise when a gear is engaged
The gear selector lever vibrates.
