Removing brake caliper
WARNING: This page is about a different car, the 2002 Volvo C70, 2001 Volvo C70, 2000 Volvo C70, 1999 Volvo C70, and 1998 Volvo C70. However, it is still accessible from the selected car via links, so may be relevant.
- Remove both caliper mounting bolts and remove brake pipe from its mountings. If removing the LH brake caliper, you will also need to remove the mounting bolt for the brake pipe three- way connector.
- Remove brake caliper.
- Hang brake caliper from a steel wire in the spring to avoid damaging brake pipe.
