Removing Loudspeakers

WARNING: This page is about a different car, the 2002 Volvo C70, 2001 Volvo C70, 2000 Volvo C70, 1999 Volvo C70, and 1998 Volvo C70. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Loudspeaker Grilles

Courtesy of VOLVO CARS OF NORTH AMERICA.

Remove

loudspeaker grilles, left and right.
plastic plugs (2) from loudspeakers, left and right. Press the center of the plastic plug to loosen it before removing.
loudspeakers, left and right.
connectors from loudspeakers, left and right.
screws Torx 25 by right loudspeaker. See (2) in figure.
