Warning and information decals inside the car

WARNING: This page is about a different car, the 2002 Volvo C70, 2001 Volvo C70, 2000 Volvo C70, 1999 Volvo C70, and 1998 Volvo C70. However, it is still accessible from the selected car via links, so may be relevant.

Decals located in the following positions call attention to the fact that the car is equipped with SRS and that it requires special treatment.

Fig 1: Identifying SRS Warning Decal

Courtesy of VOLVO CARS OF NORTH AMERICA.

On the windscreen

Shows that the car is equipped with SRS.

The SRS decal is combined with a SIPS bag decal.

Fig 2: Identifying SRS Warning Decal

Courtesy of VOLVO CARS OF NORTH AMERICA.

In the engine compartment, on the suspension turret and the steering column junction

Never undo the steering column or steering gear without first locking the contact reel and removing the steering wheel.

Fig 3: Identifying SRS Air Bag Date Label

Courtesy of VOLVO CARS OF NORTH AMERICA.

On B pillar

Airbag modules and pyrotechnic seat-belt tensioners must be inspected or replaced after a specified period.

The SRS label on the B pillar, shows the year and month for the inspection of the steering wheel module (driver airbag) and the passenger module (passenger airbag).

Replacing steering wheel module/passenger module airbag

When replacing the steering wheel module/passenger module airbag the decal with year and month must be replaced with the decal included with the new steering wheel module/passenger module.

The figure above shows the replacement of the steering wheel module date decal.

Fig 4: Identifying Child Seat Warning

Courtesy of VOLVO CARS OF NORTH AMERICA.

On the side of the dashboard on the passengers side

The decal warns against putting a child safety seat on the front passenger seat.

WARNING:

Never put a child safety seat on the front passenger seat if the car is equipped with SRS (airbag) on the passenger side.

Fig 5: Identifying Decal On Top Right Of Glove Box Lid

Courtesy of VOLVO CARS OF NORTH AMERICA.

(On the glove box lid) if the passenger module airbag is disconnected

Decal located on the top right of the glove box lid shows that the passenger module airbag is disconnected.

The four-language decal is used in all markets (except Sweden).

The Swedish language decal is used in the Nordic countries (Swedish, Norwegian, Danish, Icelandic and Finnish markets) and is located immediately below the four language decal.

CAUTION:

The passenger airbag module SRS ignition cable can be disconnected in accordance with the car owner's wishes in markets where this does not conflict with statutory requirements. This allows a rear facing child seat to be placed on the front passenger seat.

On sun visor (USA/Canada only)

In USA/Canada cars there is an SRS decal on the inside of the sun visor. This decal is not illustrated.
