RH side:

WARNING: This page is about a different car, the 2002 Volvo C70, 2001 Volvo C70, 2000 Volvo C70, 1999 Volvo C70, and 1998 Volvo C70. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Nuts Holding Link Arm/Ball Joint

Courtesy of VOLVO CARS OF NORTH AMERICA.

Remove splashguard under engine. (Earlier models only.)

Remove driveshaft support bearing cover.

Pull out driveshaft innards, bending McPherson strut back

Let driveshaft end rest on pipe running to steering gear.
