Replacing the Rear Section

Fig 1: Removing Armrest Assembly By Twisting And Pulling Straight Up

GLL107125

Courtesy of VOLVO CARS OF NORTH AMERICA.

Open the armrest
Unclip the blind cover plug for the hinge. Use a screwdriver
Slide the cover forward
Remove the two screws for the armrest
Remove the armrest assembly by twisting it and pulling it straight up
Slacken off the two screws for the rear section under the hinge mounting
Unclip the mounting at the rear edge
Fold the rear section backwards
Pull straight upwards and outwards.
