Carphone antenna/GPS antenna

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2006 Volvo S80, 2005 Volvo S80, 2004 Volvo S80, 2003 Volvo S80, and 2002 Volvo S80. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Carphone Antenna/GPS Antenna

Courtesy of VOLVO CARS OF NORTH AMERICA.

The GPS and carphone antennas are directly connected to the phone module (PHM). The antennas are in the front windshield in front of the rear view mirror.

There are diagnostics for both the GPS and car phone antennas.
