Final check

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2006 Volvo S80, 2005 Volvo S80, 2004 Volvo S80, 2003 Volvo S80, and 2002 Volvo S80. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Upper And Center Screws On Left Hand Slide Mounting

Courtesy of VOLVO CARS OF NORTH AMERICA.

Test run the heater. Check the function of the heater. See Engine coolant heater, test running .

Check that no diagnostic trouble codes (DTC) have been stored during the repair work.

Install:

the two upper screws as shown and the center screw on the left hand slide mounting
the bumper cover. See Casing, bumper front, replacing
the air baffle
the battery lead. See Battery, disconnecting .
