Installing Rear Anti-Roll Bar

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2006 Volvo S80, 2005 Volvo S80, 2004 Volvo S80, 2003 Volvo S80, and 2002 Volvo S80. However, it is still accessible from the selected car via links, so may be relevant.

NOTE:

To ensure that there is no exhaust leakage, see: Flanged joint, assembling .

Fig 1: Removing/Installing Anti-Roll Bar From Outer Mountings Using A Torx Wrench As A Counter Hold

Courtesy of VOLVO CARS OF NORTH AMERICA.

NOTE:

The parking brake cable should lie above the anti-roll bar.

Insert the anti-roll bar on the right-hand side first. Insert the left-hand side of the anti-roll bar past the removed shock absorber
Install the screws holding the anti-roll bar in the sub-frame. Tighten to 80 Nm
Install the right-hand rear outer mounting for the anti-roll bar. Finger tighten.

Fig 2: Shock Absorber In Control Arm

Courtesy of VOLVO CARS OF NORTH AMERICA.

Install the shock absorber in the control arm. Tighten the nut loosely.

Fig 3: Tightening Nuts On Anti-Roll Bar Using A Torx-Wrench As A Counter Hold

Courtesy of VOLVO CARS OF NORTH AMERICA.

Lift the wheel unit using a mobile jack. Locate the anti-roll bar link
Tighten the nuts on the anti-roll bar. Tighten to 80 Nm on both sides.
NOTE:
Use a Torx-wrench as a counterhold so that the boot is not damaged.

Fig 4: Rear Anti-Roll Bar Components

Courtesy of VOLVO CARS OF NORTH AMERICA.

Install:

parking brake cable mounting. Tighten to 25 Nm
the plastic clip for the parking brake cable on the tie rod
the exhaust pipe. See: Exhaust system, replacing . Tighten the six mounting points. Tighten to 25 Nm .
NOTE:
Install a new flange gasket.

lower the car.

Drive the car onto a wheel track hoist. Tighten the lower screw for the shock absorber. Tighten to 80 Nm .
