Removing The Carphone Antenna

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2006 Volvo S80, 2005 Volvo S80, 2004 Volvo S80, 2003 Volvo S80, and 2002 Volvo S80. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Aligning Interior Lighting On Gear Selector Module Antenna Locating Pins

Courtesy of VOLVO CARS OF NORTH AMERICA.

Remove:

the right-hand A-post panel. See Panel, A-post, replacing
the interior lighting:
- For -2002, see Interior lighting and upper electronic module (UEM), replacing
- For 2003-, see Interior lighting, replacing .

Remove the sun visor and the snap fastener. See Sun visor, replacing .

Carefully pry the headlining downwards at the front.

Remove the antenna from the mountings (1).

Expose the antenna cable and disconnect the connector positioned down by the right-hand A-post.

Fig 2: Locating Antenna At Right Hand A-Post

Courtesy of VOLVO CARS OF NORTH AMERICA.
