Wiper And Washer Components

Fig 1: Wiper And Washer Components
GLL103178Courtesy of VOLVO CARS OF NORTH AMERICA.
  1. Headlamp wiper motor
  2. Windshield wiper mechanism and wiper motor
  3. Washer fluid reservoir
  4. Washer nozzle.
