Detaching And Cleaning the Bumper Cover

Materials

Description  Number  P/N
Hot adhesive 0.1 1161655
White spirit 0.1 1161450
Cleaner H 0.2 1161436
Fig 1: Detaching And Cleaning Bumper Cover
GLL105130Courtesy of VOLVO CARS OF NORTH AMERICA.

Slacken off the fender liner at the front edge. Bend the fender liner so that the upper inner corner of the bumper is accessible.

Clean the shaded area in the illustration thoroughly. Use white spirit. (The illustrations display the inside of the bumper).

Thoroughly clean using Cleaner-H.
