Oil Pan: Removal

Position lifting tools (5006, 5033 & 5115) as shown in Fig 1. Disconnect A/C compressor (if equipped). Remove bolts from left engine mount. Lift engine slightly and drain oil. Remove splash guard, left engine mount, and brace. Remove bolts from oil pan and tap to loosen.

Fig 1: Removing Oil Pan

Courtesy of VOLVO CARS CORPORATION
