Lock Cylinder, Removing And Installing: Installing

WARNING: This page is about a different car, the 2023 Volkswagen Atlas. However, it is still accessible from the selected car via links, so may be relevant.

Install in the reverse order of removal while noting the following:

-- Insert the ignition key into the lock cylinder and turn it to the ignition "on" position.

-- Slide the Locking Pin (3 pc.):T40011 or a suitable welding wire (if necessary) all the way into the front hole again.

-- Connect the connector to the anti-theft immobilizer reader coil.

-- Insert the lock cylinder -1- with the reader coil into the steering lock housing -3-.

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- Remove the Locking Pin (3 pc.):T40011 from the hole -2-.

-- Push the lock cylinder in firmly until the locking mechanism engages audibly.
