C-Pillar Air Ducts, Removing And Installing: Removing

WARNING: This page is about a different car, the 2023 Volkswagen Atlas. However, it is still accessible from the selected car via links, so may be relevant.

-- Remove the C-pillar trim panel. Refer to COMPONENT LOCATION OVERVIEW - VEHICLE INTERIOR TRIM PANELS .

-- Remove the air duct -1-.

GWWN87-11607Courtesy of AUDI OF AMERICA, LLC
