Tiptronic Downshift Button on Steering Wheel -E439- /Tiptronic Upshift Button on Steering Wheel -E438-, REMOVING AND INSTALLING: Removing

WARNING: This page is about a different car, the 2023 Volkswagen Arteon. However, it is still accessible from the selected car via links, so may be relevant.

-- Remove the decorative trim with multifunction buttons. Refer to Left Multifunction Buttons on Steering Wheel -E440- /Right Multifunction Buttons on Steering Wheel -E441-, REMOVING AND INSTALLING .

-- Remove the bolt -1- on the steering wheel.

Fig 1: Identifying Bolt And Tiptronic Downshift Button On Steering Wheel

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- Remove the Tiptronic switch -2- with the connecting cable toward the rear.
