Overview - Engine PREHEATER
WARNING: This page is about a different car, the 2015 Volkswagen Jetta. However, it is still accessible from the selected car via links, so may be relevant.
- Rubber Protector
- Engine Preheating Element -Z97-
- Coolant Hose Connection Diagram. Refer to CONNECTION DIAGRAM - COOLANT HOSES, VEHICLES WITH SELECTIVE CATALYTIC REDUCTION (SCR) .
- Clamp
- Bolt
- 8 Nm
- Bracket
- Connecting Cable
- Connected to the Engine Preheating Element -Z97-
- Bracket
- Upper Section
- To the wiring harness retainer in the air grille
- Bracket
- Lower Section
- To the wiring harness retainer in the air grille
- Air Grille
- Front
