Part II
WARNING: This page is about a different car, the 2023 Volkswagen Atlas. However, it is still accessible from the selected car via links, so may be relevant.
Part I. Refer to Part I .
- Cylinder Head
- O-Ring
- Replace if damaged
- Coat with engine oil
- Cam Adjustment Actuator
- Allocation. Refer to Fig 2.
- Bolt
- 5 Nm
- Ball Pin
- For the engine cover
- 9 Nm
- O-Ring
- Replace if damaged
- Coat with engine oil
- Plugs
- O-Ring
- Replace
- Coat with engine oil
- Camshaft Position Sensor 3 -G300-
- Overview. Refer to OVERVIEW - IGNITION SYSTEM .
- Bolt
- Tightening specification Refer to OVERVIEW - IGNITION SYSTEM .
- Oil Separator
- Removing and Installing. Refer to OIL SEPARATOR, REMOVING AND INSTALLING .
- Bolt
- Tightening specification and sequence. Refer to Fig 3.
- Seal
- Replace if damaged
- Vacuum Pump
- Removing and Installing. Refer to VACUUM PUMP, REMOVING AND INSTALLING .
- Bolt
- Replace
- 8 Nm +180°
- Seal
- Replace after removing
- O-Ring
- Replace
- Coat with engine oil
- Camshaft Position Sensor -G40-
- Overview. Refer to OVERVIEW - IGNITION SYSTEM .
- Bolt
- Tightening specification Refer to OVERVIEW - IGNITION SYSTEM .
- Bolt
- 9 Nm
- Bracket
- For the EVAP Canister Purge Regulator Valve 1 -N80-
