Overview - Parallel Parking Assist, Sedan

Fig 1: Parallel Parking Assist

Courtesy of AUDI OF AMERICA, LLC

Parallel Parking Assistance Button -E581-
- Removing and installing. Refer to Parallel Parking Assistance Button -E581-, REMOVING AND INSTALLING .
Rear Parallel Parking Assist Sensors
- Left Rear Parallel Parking Assistance Sensor -G716-
- Right Rear Parallel Parking Assistance Sensor -G717-
- Removing and installing. Refer to REAR SENSOR, REMOVING AND INSTALLING .
Bracket
- For Parallel Parking Assistance Control Module -J791-
- Removing and installing. Refer to Parking Aid Control Module -J446- /Parallel Parking Assistance Control Module -J791- BRACKET, REMOVING AND INSTALLING .
Parallel Parking Assistance Control Module -J791-
- Removing and installing. Refer to CONTROL MODULE, REMOVING AND INSTALLING .
Parallel Parking Assist Front Sensor
- Left Front Parallel Parking Assistance Sensor -G568-
- Right Front Parallel Parking Assistance Sensor -G569-
- Removing and installing. Refer to FRONT SENSOR, REMOVING AND INSTALLING .
