Overview - Automatic Headlamp Range Control
NOTE:
The Sedan is shown. The Wagon is identical.
- Cornering Lamp and Headlamp Range Control Module -J745-
- On the mounting bracket pedal assembly
- Removing and installing. Refer to Cornering Lamp and Headlamp Range Control Module -J745-, REMOVING AND INSTALLING .
- Left Rear Level Control System Sensor -G76-
- On the rear control arm
- Overview. Refer to OVERVIEW - REAR LEVEL CONTROL SYSTEM SENSOR .
- Left Headlamp Beam Adjustment Motor -V48-
- Removing and installing. Refer to LEFT AND RIGHT HEADLAMP BEAM ADJUSTMENT MOTOR -V48- / -V49-, REMOVING AND INSTALLING .
- Right Headlamp Beam Adjustment Motor -V49-
- Removing and installing. Refer to LEFT AND RIGHT HEADLAMP BEAM ADJUSTMENT MOTOR -V48- / -V49-, REMOVING AND INSTALLING .
