Overview - Body Tail Lamps, With Led
WARNING: This page is about a different variant/trim than selected.
- Left Tail Lamp -MX3- /Right Tail Lamp -MX4-
- Left Tail Lamp -MX3-
- Right Tail Lamp -MX4-
- Removing and Installing . Refer to TAIL LAMP, REMOVING AND INSTALLING .
- Fastening Element
- 2 Nm
- Turn Signal Bulb Socket
- Left Rear Turn Signal Bulb -M6- /Right Rear Turn Signal Bulb -M8-
- Left Rear Turn Signal Bulb -M6-
- Right Rear Turn Signal Bulb -M8-
- Removing and Installing . Refer to TURN SIGNAL BULB, REMOVING AND INSTALLING, TAIL LAMPS WITH LEDS .
- Back-Up Lamp Bulb Socket
- Left Back-Up Lamp Bulb -M16- /Right Back-Up Lamp Bulb -M17-
- Left Back-Up Lamp Bulb -M16-
- Right Back-Up Lamp Bulb -M17-
- Removing and Installing . Refer to BACK-UP LAMP BULB, REMOVING AND INSTALLING, TAIL LAMPS WITH LEDS .
