Low Beam Headlamp Bulb, Removing And Installing: Removing

-- Turn off the ignition and all electrical equipment and remove the ignition key.

-- Remove the headlamp. Refer to HEADLAMP, REMOVING AND INSTALLING .

-- Turn the housing cover -2- on the headlamp -1- in the direction of the -arrow- and remove it.

Fig 1: Identifying Cap And Headlamp

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- Disconnect the connector -1- from the Left Low Beam Headlamp Bulb -M29- -3- in the direction of the -arrow B-.

Fig 2: Identifying Left Low Beam Headlamp Bulb With Wire Clip And Connector

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- Push the wire clip -2- forward and in the direction of the -arrow A-.

-- Unclip the wire clip and remove the Left Low Beam Headlamp Bulb -M29- -3- from the headlamp.
