Overview - Spoiler, Sedan

WARNING: This page is about a different variant/trim than selected.

Fig 1: Spoiler Overview, Sedan

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

Rear Spoiler
- There are different versions. Refer to the parts information.
- Removing and Installing. Refer to SPOILER, REMOVING AND INSTALLING, SEDAN .
Rear Lid
Adhesive Tape
- 2 strips for the side mountings for the rear spoiler
Nut
- 6 Nm
- Quantity: 6
Adhesive Bead
- Bead diameter: Width -b- = 9 mm, height -a- = 6 mm (including residual material on rear spoiler and rear lid).
