Overview - Door Trim Molding And Side Panel

WARNING: This page is about a different variant/trim than selected.
NOTE:

The illustration shows the left side. The right side is identical.

Fig 1: Door And Side Panel Trim Strip
GWWM66-10048Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
  1. Side Panel Trim Molding
  2. Door Trim Molding
  3. Clip
    • Door trim molding quantity: 7
    • Side panel trim molding quantity: 3
  4. Grommet
    • Door quantity: 7
    • Side panel quantity: 3
  5. Bolt
    • 1.5 Nm
    • Door trim molding quantity: 2
  6. Adhesive Tape
    • Replace if using undamaged trim moldings again
