Adjusting Buffer, Removing and Installing

Removing

Fig 1: Identifying Adjusting Buffer

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- Turn the entire adjusting buffer -1- 90° to the left in direction of -arrow a-.

-- Finally, remove the adjusting buffer from the rear lid -2- in direction of -arrow b-.

Installing

Fig 2: Identifying Adjusting Buffer

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- Insert the adjusting buffer -1- at a right angle into the rear lid -1- in direction of -arrow a-.

-- Then turn adjusting buffer 90° to the right in direction of -arrow b-.
