Overview - Rear Lid, Sedan: Hinge
WARNING: This page is about a different variant/trim than selected.
- Hinge
- Removing and Installing. Refer to HINGES, REMOVING AND INSTALLING .
- Bolt
- 10 Nm
- Quantity: 2 on each side
- Washer
- If equipped. Refer to the Parts Information for the allocation.
- Nut
- 24 Nm
- Quantity: 1 on each side
- Rear Lid
- Removing and Installing. Refer to REAR LID, REMOVING AND INSTALLING, SEDAN .
- Adjusting. Refer to REAR LID, ADJUSTING, SEDAN .
