Emergency Release
WARNING: This page is about a different variant/trim than selected.
- Release Lever
- For the release cable
- Locks into the side trim panel. Refer to SIDE TRIM PANEL, CONVERTIBLE .
- Release Cable Bracket
- Attached to the body
- Clip
- Guide on Rear Lid Hinge
- Rear Lid Hinge
- Release Cable Coupling in Rear Lid
- Works the same as the hood release cable coupling. Refer to RELEASE CABLE, REMOVING AND INSTALLING .
- Release Cable on Rear Lid Latch
- Latch
- Opening in Body
