Overview - Wheel Bearing
WARNING: This page is about a different variant/trim than selected.
- Bolt
- 50 Nm +45°
- Replace after removing .
- Cover
- Mounting Bracket
- Bolt
- 90 Nm +90°
- Replace after removing .
- Coupling Rod
- Connects stabilizer bar to trailing arm/wheel bearing housing
- Bolt
- 90 Nm +45°
- Replace after removing .
- Note the tightening sequence. Refer to Installing .
- Bolt
- 8 Nm
- Right Rear ABS Wheel Speed Sensor -G44- / Left Rear ABS Wheel Speed Sensor -G46-
- Can be checked in Guided Fault Finding. Refer to Vehicle Diagnostic Tester.
- Before inserting the sensor, clean the inner surface of the hole and coat with Grease:G 000 650 .
- Wheel Bearing Housing
- Removing and installing . Refer to WHEEL BEARING HOUSING, REMOVING AND INSTALLING
- Wheel Bearing Seal
- Allocation. Refer to the Parts Information.
- Removing and installing . Refer to WHEEL BEARING SEAL, REMOVING AND INSTALLING
- Trailing Arm
- Removing and installing . Refer to TRAILING ARM WITH MOUNTING BRACKET, REMOVING AND INSTALLING
- Servicing. Refer to TRAILING ARM, SERVICING .
- Bonded Rubber Bushing
- Replacing. Refer to WHEEL BEARING HOUSING BONDED RUBBER BUSHING, REPLACING .
- Nut
- 45 Nm
- Replace after removing .
- Bonded Rubber Bushing
- Replacing. Refer to TRAILING ARM, SERVICING .
- Cover Plate
- Bolt
- 12 Nm
- Wheel Hub with Wheel Bearing
- The ABS sensor ring is installed in the wheel bearing
- Removing
and installing
. Refer to WHEEL BEARING UNIT, REMOVING AND INSTALLING
The wheel bearing and wheel hub are installed together in a housing.
The wheel bearing unit is maintenance free and has zero play. Adjusting as well as repair work is not possible!
- Bolt
- 200 Nm +90°
- Replace after removing .
- Loosen and tighten using Socket - Xzn 18mm: T10162A
- Dust Cap
- Replace after removing .
- Removing and installing
. Refer to WHEEL BEARING UNIT, REMOVING AND INSTALLING .
An appropriate seal can only be achieved with a new dust cap.
- Brake Rotor
- Bolt
- 4 Nm
